TP-Link TL-SG1008MP 8-Port Gigabit Desktop/Rackmount Switch with 8-Port PoE+

Professional High-Power 8-Port Gigabit
Desktop/Rackmount Switch with 8-Port PoE+

Plug and Play

The TP-Link TL-SG1008P 8-Port Gigabit Desktop/Rckmount Switch with all 8 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 126 W, up to 30 W per port, TL-SG1008MP can power more high-powered devices such as wireless Access Points (APs), IP Cameras or IP Phones. Moreover, with innovative energy-efficient technology, the TL-SG1008MP can save power consumption, making it an eco-friendly solution for your business network.

Features

Dedicated 8-Port PoE+ Switch for Wide Range of Applications with 153 W PoE Budget
Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 153 W PoE power budget* for the 8× PoE ports makes it has wide range of applications, such as surveillance, offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and etc.

System Self-Healing with PoE Auto Recovery
The TP-Link TL-SG1008P 8-Port Gigabit Desktop/Rckmount Switch automatically detects and reboots the PD devices, such as cameras and APs, when they fall offline or go unresponsive, guaranteeing the stable operation of PoE-connected devices, without need for manual monitoring and restart.

Ideal for IP Surveillance —Up to 250 m Transmissions
With extend mode, the PoE transmission distance reaches up to 250 m*—perfect for IP Camera deployment in large areas.

*The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.

Intelligent Power Management
When total power consumption exceeds 153 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

Durable Metal Casing
The interior components of TL-SG1008MP are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SG1008MP delivers switching performance you can depend on.

 Technical Specifications

HARDWARE

Interface

8 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)

Fan Quantity: 1
Physical Security: Lock No
Power Supply: 100-240VAC, 50/60Hz
Packet Forwarding Rate: 11.904 Mpps

PoE+ Ports(RJ45)
Standard: 802.3af/at compliant
PoE+ Ports: 8 Ports
Power Supply: 153W

Mac Address Table: 4K
Buffer Size: 1.5Mbits
Jumbo Frame: 16 KB
Switching Capacity: 16Gbps

Max Power Consumption
• 8.77 W(220V/50Hz. no PD connected)
• 172.49 W(110V/60Hz. with 153W PD connected)

Max Heat Dissipation
• 29.91 BTU/h(no PD connected)
• 588.19 BTU/h(with 153W PD connected)

SOFTWARE

Advanced Features

• Compatible With IEEE 802.3af/at Compliant PDs
• Priority Function
• Mac Address Auto-Learning And Auto-Aging
• IEEE802.3x Flow Control for Full-Duplex Mode and Backpressure for Half-Duplex Mode
• Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)
• PoE Auto Recovery (Ports 1-8)

Transfer Method: Store-And-Forward

OTHERS

Certification: FCC, CE, RoHS

Environment:

Operating Temperature: 0℃~50℃ (32℉~122℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Dimensions ( W x D x H ): (294 mm x 180 mm x 44 mm)
Mounting Desktop/Rack Mountable
